Introducing the Chauvet Professional Rogue R3X WASH Moving Head, the ultimate lighting solution for creating mesmerizing visual effects. With its fully featured RGBW LED yoke wash fixture, this lighting fixture offers unparalleled control and versatility. Featuring 37 RGBW LEDs, each with a powerful 25W output, the Rogue R3X WASH delivers vibrant and dynamic colors that will transform any space. The unique lens design ensures excellent color mixing, allowing you to create stunning lighting displays with ease. Experience smooth and precise control over your fades with the 16-bit dimming of the master dimmer and individual colors. The fast and smooth pan and tilt movement add an extra layer of dynamism to your lighting effects, captivating your audience from every angle. The Rogue R3X WASH is equipped with 9 zones of LED control, enabling you to create mesmerizing pixel mapping effects. With 3- and 5-pin DMX input/output connections, this fixture seamlessly integrates into any lighting setup. Designed for maximum convenience, the Rogue R3X WASH features RDM compatibility for remote addressing and troubleshooting. The selectable LED maximum output allows you to match the performance of legacy Rogue R3 Washes effortlessly. With 6 distinct dimming modes, this fixture adapts to different dimming needs, giving you complete control over the ambiance of your space. The Omega mounting bracket ensures easy installation, fitting all Rogue and Maverick fixtures. Navigating through the settings is a breeze with the easy-to-read OLED display and simple menu options. Whether you're a lighting professional or a beginner, the Rogue R3X WASH offers simple and complex DMX channel profiles for programming versatility. Get ready to elevate your lighting game with the Chauvet Professional Rogue R3X WASH Fixture. Its exceptional features and outstanding performance make it the perfect choice for concerts, events, theaters, and more. Illuminate your world and captivate your audience with this extraordinary lighting fixture.
Specifications
OPTICAL
Light Source: 37 LEDs (quad-color RGBW) 25 W, (1.5 A), 50,000 hours life expectancy
Color Temperature (range): 2,800 to 10,000 K
Beam Angle: 9.3° to 33.9°
Field Angle: 11.6° to 49.5°
Zoom Angle: 11.6° to 49.5°
Lumens – Source: 17,000
Lumens – Output: 13,440
Illuminance (11.6°): 18,260 lux @ 5 m
Illuminance (49.5°): 1,556 lux @ 5 m
Selectable PWM: 600 Hz, 1,200 Hz, 2,000 Hz, 4,000 Hz, 6,000 Hz, 15,000 Hz
DYNAMIC EFFECTS
Pan and Tilt: 540°/230°
Pan and Tilt Ranges: 180°, 360°, 540° Pan/90°, 180°, 230° Tilt
Dimmer: Electronic
Shutter/Strobe: Electronic
Zoom: Motorized
Strobe Rate: 0 to 20 Hz
Standalone Color Mixing: Yes
Color Temperature Presets: Yes
Dim Curves: 4
Built-in Automated Programs: Yes
Customizable Programs: No
Recall Custom Programs: No
CONSTRUCTION / PHYSICAL
Dimensions: 15.51 x 11.73 x 18.50 in (394 x 298 x 470 mm)
Weight: 38.5 lb (17.46 kg)
Exterior Color: Black
Housing Material: High-impact flame-retardant polymer
CONNECTIONS
Power Connection: Edison (local) plug to Neutrik® powerCON®
Power Input: Neutrik® powerCON®
Power Output: Neutrik® powerCON®
Data Connectors: 3- and 5-pin XLR
Cable Length (power): 5 ft (1.5 m)
CONTROL
Control Protocol: DMX, RDM
DMX Channels: 21, 62, 71, 107
Modes/Personalities: 4 personalities
ELECTRICAL
Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
Power Linking: 2 units @ 120 V; 3 units @ 208 V; 4 units @ 230 V
Power and Current: 661 W, 5.60 A @ 120 V, 60 Hz
Power and Current: 653 W, 3.136 A @ 208 V, 60 Hz
Power and Current: 650 W, 2.85 A @ 230 V, 50 Hz
CERTIFICATIONS / QUALIFICATIONS
CE, MET, FCC, UKCA
IP Rating: IP20, dry location
WHAT'S INCLUDED
Rogue R3X Wash
Neutrik® powerCON® power cord
2 Omega brackets with mounting hardware
OPTIONAL ACCESSORIES
Professional Clamps: CTC-50HC, CTC-50HCN
Safety Cable: SC-07
Neutrik® powerCON® cables
DMX Cables
Flight Case: CP4CASER3W
